2026 Jeep Wrangler Towing Capacity
For Gulfport drivers, the 2026 Jeep Wrangler is more than an off-road toy; it is a functional utility vehicle. A critical update for the 2026 model year is the continuation of the 5,000-pound maximum towing capacity on specific configurations. This capability moves the Wrangler from a light-duty tow vehicle into a class capable of hauling bay boats and heavier dual-axle trailers.
Achieving this rating requires specific hardware. Below is the complete technical breakdown of the 2026 Wrangler's towing capabilities, engine outputs, and physical dimensions.
Towing Capacity by Trim and Engine
Not all Wranglers are rated equally. The towing capacity changes drastically based on door count, transmission, and axle type.
Engineering Insight: The Full-Float Axle The jump to 5,000 pounds on the Rubicon automatic models is made possible by the Dana 44 HD Full-Float Rear Axle.
In a standard "semi-float" axle (found on Sport and Sahara), the axle shaft supports both the vehicle's weight and the torque load. In the "full-float" design found on the Rubicon, the weight of the vehicle is transferred directly to the axle tube. The axle shaft is subjected only to torsional forces (turning the wheels). This separation of stresses allows for significantly heavier loads without risking axle fatigue.
Engine Performance Specifications
2.0L Turbo I-4
- Horsepower: 270 hp @ 5,250 rpm
- Torque: 295 lb-ft @ 3,000 rpm
- Application: Standard on Sahara and Sport S; creates peak torque low in the rev range, ideal for city driving in Gulfport.
3.6L Pentastar V-6
● Horsepower: 285 hp @ 6,400 rpm
● Torque: 260 lb-ft @ 4,800 rpm
● Application: Standard on Sport and Rubicon. This is the only engine available with the 6-speed manual transmission.
6.4L HEMI® V-8
- Horsepower: 470 hp @ 6,000 rpm
- Torque: 470 lb-ft @ 4,300 rpm
- Application: Standard on Moab 392. Provides instantaneous throttle response and high-speed passing power.
Critical Dimensions for Off-Roading
Beyond the engine bay, the Wrangler's physical footprint determines its capability on trails like the Rattlesnake Bay ATV trails.
Ground Clearance
The standard Sport sits at 9.7 inches, while the high-performance Moab 392 rides at 11.1 inches.
Water Fording
The Moab 392 and Rubicon models equipped with the Xtreme 35 Package can traverse standing water up to 34.0 inches deep.
Crawl Ratio
Manual transmission Rubicon models feature a 4:1 low-range transfer case and 4.10 axle gears. When combined, this offers exceptional control for low-speed maneuvering over technical obstacles.
